5-Axis Vertical Machining Centres

The high-speed, high-precision 5-axis machining centre enables ultra-high-precision simultaneous 5-axis control for aviation and medical parts and 4+1-axis control for the economically feasible multi-facet/complex shape machining, depending on customer needs.

FEATURED 5-Axis Vertical Machining Centre - TONGTAI GT-630

Gantry type structure, moving axes driven at the center of gravity, dynamic capabilities greatly improved

5-axis simultaneous machining can complete complex processes in one-sitting

High rigidity structure with closed design

Gantry type movement, 3-axis feed rate will not affected by workpiece’s weight

Adopts oil air lubrication spindle, provides low heat and reach long lifetime feature

5-axis trunnion table is driven by built-in DD motor, allowing for high precision and high rotation speed

tongtai_gt-630_yellow
tongtai_gt-630_blue

Technical Specifications

Specification GT-630
Table size(LxW) Ø630 mm
Max. loading capacity 600 kg
X/Y/Z axis travel 760/820/560 mm
A/C axis travel +30°~-120°/±360° deg
X/Y/Z axis rapid rapid traverse 48/48/48 m/min
A/C axis rapid rapid traverse 50/100 rpm
Spindle taper 7/24 Taper No.40
Spindle speed 15000(20000) rpm
Spindle motor 40/40(Opt. 42/35) kW
Tool capacity 32(Opt. 40/64/80) pc

For more information on the Tongtai GT-630 or any of our other 5-Axis Vertical Machining Centres, please call us on 01372 844999.
