Turn-mill operations, with lathe, vertical or horizontal machining centre and material handling operations consolidated into one 8-10 inch chuck class machine.
These multi-tasking CNC machines perform process-intensive machining for shorter deliveries, while making more effective use of floor space. With fewer setups, work in process is drastically reduced and machine utilisation is greatly increased.
Applies single power turret for turning and milling process
75 degree lathe structure allowing for good chip removal and controllability
Low machine gravity center, allowing for overall structure to have good rigidity
X/Y/Z-axis are orthogonal to each other, allowing for high straightness and positioning accuracy
|Chuck O.D.||8″ inch|
|Bar capacity||Ø51(Opt. built-in type Ø51) mm|
|X/Y/Z/B axis travel||230/±51/600/ mm|
|X/Y/Z/B axis rapid traverse||30/15/30/ m/min|
|Spindle speed||4,500 (Opt. 3,500) rpm|
|Spindle motor||18.5/15/11 kW|
|Sub-spindle chuck O.D.||[6″] inch|
|Sub-spindle speed||[5,000] rpm|
|Sub-spindle motor||[7.5/5.5] kW|
|Tool capacity||12 pc|
