High Speed Drill Tapping Machines
A CNC Tapping Centre is a numerically controlled machine tool used for machining parts in every industrial field, featuring high speed, high accuracy, and high productivity.
Development of Tapping Centres has enabled milling and fine boring in addition to tapping, achieving high productivity, improved machining capabilities, and greater reliability that shatter conventional common sense.
FEATURED High Speed Drill Tapping Machine - TONGTAI VTX-5[A]
High speed tool changer, only 1.2 seconds for T-T
High rigidity roller type linear guide way
Direct drive spindle design, high acceleration/deceleration reactivity, rigid tapping of up to 6000rpm
Spindle shaft’s radius up to 50mm, enhancing cutting rigidity
Maximum torque for spindle motor of up to 82 Nm
Technical Specifications
| Specification | VTX-5[A] |
|---|---|
| Table size(LxW) | 600×400 mm |
| Max. loading capacity | 250 kg |
| X/Y/Z axis travel | 510/400/300[350] mm |
| X/Y/Z axis rapid traverse | 60/60/60 m/min |
| Spindle taper | 7/24 Taper No.30 |
| Spindle speed | 12000(20000/24000) rpm |
| Spindle motor | 3.7/13(3.7/5.5) kW |
| Tool capacity | 16(21) [20] pc |
